B-1B-1 | Berth, Modular, Crew and Troop (cont’d)
Intended Use: In Crew and Troop Berthing Spaces
SFC No. B-1B-1 3 of 5
Hull Type Drawing No. 804-5959312
NSN: None
Principal Material: Aluminum
Remarks: Berths are designed to accommodate following mattresses in accordance with specification MIL-M-18351 (see 1D-1 when ordering mattresses.)
- Size 1 Berth: Type 1, Size 1 mattress.
- Size 2 Berth: Type 1, Size 2 mattress.
- Size 3 Berth: Type 1, Size 3 mattress.
Mattress clearance is measured from top of mattress to underside of berth or locker over or to top of berth enclosure for upper berth.
Whenever a berth is provided without a locker under, a locker of equal volume shall be provided.
Original price was: $1,000.00.$400.00Current price is: $400.00.
Additional Information
| Mattress | Length | Width | Height | ||||
| Type | Style | Clearance | Size 1 | Size 2 | Size 3 | ||
| V | 1 | 460 (18) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 2310 (91) |
| VI | 1 | 460 (18) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1440 (56-¾) |
| 2 | 510 (20) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1540 (60-¾) | |
| VII | 1 | 460 (18) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1250 (49-¼) |
| 2 | 510 (20) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1350 (53-¼) | |
| VII | 1 | 460 (18) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1240 (49) |
| 2 | 510 (20) | 1920 (75-¾) | 2010 (79-¼) | 2110 (83-¼) | 700 (27-¾) | 1350 (53) |
Order Options: Ordering Information must include the following:
- Type, Style, Size, and Hull Type Drawing Number.
- Units can be ordered without back and end panels to save weight.
- Fan Units.
- Curtains and track see sheet B-2B-3
| Standard Bed | Height – 2240 (88-¼), Width – 1250 (49-¼), Height – 610 (24), Weight kg (lb) – 117.0 (258) |
|---|---|
| Long Bed Complete as Shown | Height – 2390 (94-1/4), Width – 1250 (49-1/4), Height – 610(24), Weight kg (lb) – 121.6 (268) |
