B-2A-11 | ​​Chest of Drawers

See Sizes

Intended Use: In Staterooms or Senior Officer Quarters if Modular Units are not suitable

Download PDF

SFC No. B-2A-11
Hull Type Drawing No. No. S3306-630290
NSN: H2090-00-267-3434

Principal Material: Aluminum

Remarks:

  • Chest of Drawers can be used individually or with other units to form groups of furniture.
  • Basic unit can become a Chiffonnier by the addition of a 21″ high locker unit stacked on top of the Chest of Drawers (See Hull Type Drawing S3306-630290).
  • Locker is fitted with one adjustable shelf and double swinging doors.
  • Chest of Drawers, when located in cabins or single staterooms, is to be fitted with a lock in the top drawer only; when located in double staterooms, is to be fitted with locks in top drawer and fourth drawer from top as shown in the photograph.
  • The locker is also detailed on the above referenced Hull Type Drawing.
  • Unit is furnished with a sub-base (See Hull Type Drawing No. S3306-921770).

*Sub-base is not included in these figures.

Original price was: $1,000.00.Current price is: $400.00.

Sale!
B-2A-11 | ​​Chest of Drawers

Additional Information

Size Millimeters (Inches)

Width Depth Height Weight kg (lb)
900 (35-¼) 540 (21-⅛) 1360 (53-13/32) 65.3 (144)
Standard Bed

Height – 2240 (88-¼), Width – 1250 (49-¼), Height – 610 (24), Weight kg (lb) – 117.0 (258)
Long Bed Complete as Shown

Height – 2390 (94-1/4), Width – 1250 (49-1/4), Height – 610(24), Weight kg (lb) – 121.6 (268)
